Lighting Effects
Diffuser linear , creat flood light in different length
Applacation Emagery
Home , hotel , resturant , shoppes ,office
Product Details
High brightness, low light decline
Owns unique and attractive design
Creat a circle of light from a line of LED downlight
Anarrow line ofnano LED downlights for pure minimalism
Superiorglare control for high performance and visual comfort
The installation is easy and safe
Specification
| Model | Dimension | Cutout | Output Wattage | Source Current | Source voltage | Beam Angle | Color Temperature | Luminous Flux | CRI | Dimming |
| BLD0510 | 136.5*34*70mm | 10W | 250mA | 15V | 15°/30°/45° | 2700-6000K | 800lm | >90Ra | on-off /0-10V dim/Triac dim/DALI dim | |
| BLD1020 | 269*34*70 mm | 20W | 600mA | 30V | 15°/30°/45° | 2700-6000K | 1600lm | >90Ra | on-off /0-10V dim/Triac dim/DALI dim | |
| BLD1530 | 402*34*70 mm | 30W | 600mA | 45V | 15°/30°/45° | 2700-6000K | 2400lm | >90Ra | on-off /0-10V dim/Triac dim/DALI dim | |
| BLD0312 | L118xW42mmXH54mm | 12W | 36V | 15°24°38°50°50°x50° 70°x70° 35°x70° | 2700-6000K | 1056lm | >90Ra | on-off /0-10V dim/Triac dim/DALI dim | ||
| BLD0520 | L193xW42mmXH54mm | 20W | 15°24°38°50°50°x50° 70°x70° 35°x70° | 2700-6000K | 1760lm | >90Ra | on-off /0-10V dim/Triac dim/DALI dim | |||
| BLD1040 | L383xW42mmXH54mm | 40W | 15°24°38°50°50°x50° 70°x70° 35°x70° | 2700-6000K | 3520lm | >90Ra | on-off /0-10V dim/Triac dim/DALI dim |
