DLT Economic Series Recessed Downlight - KWT LED

DLT Economic Series Recessed Downlight

HDLS75-TR Effect

Lighting Effects

Wide beam angle , IP44 protection grade , available for office , corridor ,bath room ,showroom

Applacation Emagery

Wide beam angle , IP44 protection grade , available for office , Shopping mall , corridor ,bath room ,showroom

106786669_133309498414665_3404482069044800058_n

Product Details

1. High brightness，Low SDCM＜3，low light decline
2. High efficacy,high illuminance、accurate beam angle makes comfortable illumination atmosphere、Refined components and design
3. guarantee a long lifespan of over 40,000 hours
4. Triac,0-10v,Dali dimmable is available
5. Easy installation,Widey used in Airport,train station,exbition center,hotel lobby,office ect.

Specification

Model	Dimension	Cutout size	Wattage	Source Current	Source voltage	Beam Angle	Color Temperature	Luminous Flux	CRI	Dimming
DLT0203	∅90*H55mm	∅75mm	3W	250mA	9V	45°	2700K-6500K	317lm	>90Ra	Triac Dim /0-10V dim/Dali
DLT0205	∅90*H55mm	∅75mm	5W	280mA	18V	45°	2700K-6500K	422lm	>90Ra	Triac Dim /0-10V dim/Dali
DLT0207	∅90*H55mm	∅75mm	7W	180mA	36V	45°	2700K-6500K	522lm	>90Ra	Triac Dim /0-10V dim/Dali
DLT0310	∅120*H51.5mm	∅95mm	10W	250mA	36V	90°/120°	2700K-6500K	839lm	>90Ra	Triac Dim /0-10V dim/Dali
DLT0515	∅170*H51.5mm	∅145mm	15W	350mA	36V	90°/120°	2700K-6500K	1649lm	>90Ra	Triac Dim /0-10V dim/Dali
DLT0620	∅195*H51.5mm	∅170mm	20W	500mA	36V	90°/120°	2700K-6500K	2158lm	>90Ra	Triac Dim /0-10V dim/Dali
DLT0825	∅225*H51.5mm	∅205mm	25W	600mA	36V	90°/110°	2700K-6500K	2797lm	>90Ra	Triac Dim /0-10V dim/Dali
DLT0830	∅225*H51.5mm	∅205mm	30W	720mA	36V	90°/110°	2700K-6500K	3189lm	>90Ra	Triac Dim /0-10V dim/Dali
DLT0848	∅225*H65.5mm	∅205mm	48W	1150mA	36V	90°/110°	2700K-6500K	4548lm	>90Ra	Triac Dim /0-10V dim/Dali
