Bulgari series recessed downlight

Bulgari deep anti-glare ceiling spotlight, BDL5507 is an anti-glare spotlight independently designed and developed by KWT. It is composed of various opening sizes such as 55mm, 75mm, 95mm, etc., and has a family design, including round, square, and single head. , multi-headed and borderless styles. It adopts the international top quality COB light source, with various beam angles of 15°, 25°, 36°, and 50°. It can be matched with various optical accessories. It adopts a flicker-free high-quality driver and can be adapted to non-dimming, thyristor, and 0 -10V, DALI, PLC, ZIGBEE, Bluetooth and other different dimming control systems

1 2

Lighting Effects

Dapibus cras viverra magnis lectus quis placerat vel a.

Applacation Emagery

Hotel Lobby , Shopping mall , office , Stations ,and any high ceiling are all vailable .

Product Details

Structure designed in deep anti-glare to ensure the UGR<10. It creates a comfortable light environment for people;
Reflecor has different colors and shapes for options ,it meet any decoration and light distribution requirments.
The fixture head has adjustable funcation of adjust angle at vertical is 0-25 degrees, and horizontal is 350 degrees;
Modular structure for easy assembly, installation and disassembly;
Long life span more than 50000hrs .

Specification

Model	Dimension	Cutout	Output Wattage	Source Current	Source voltage	Beam Angle	Color Temperature	Luminous Flux	CRI	Dimming
BDL5507	∅62*H70mm	Ø55mm	7W	200mA	31V/DC	8°/15°/24°/38°/50°	2700K-6000K	67Lm/w*7W	Ra＞90/97	on-off /0-10V dim /Triac dim/Dali
BDL5507-A	∅55*H80mm	Ø55mm	7W	200mA	31V/DC	10°/15°/24°/38°/50°	2700K-6000K	67Lm/w*7W	Ra＞90/97	on-off /0-10V dim /Triac dim/Dali
BDLS5507	D64mm*H78mm	56*56mm	7W	200mA	31V/DC	8°/15°/24°/38°/50°	2700K-6000K	67Lm/w*7W	Ra＞90/97	on-off /0-10V dim /Triac dim/Dali
BDLS5507-A	D64mm*H85mm	55*55mm	7W	200mA	31V/DC	10°/15°/24°/38°/50°	2700K-6000K	67Lm/w*7W	Ra＞90/97	on-off /0-10V dim /Triac dim/Dali
BDL5510	∅62*H85mm	Ø55mm	10W	275mA	31V/DC	8°/15°/24°/38°/50°	2700K-6000K	67Lm/w*10W	Ra＞90/97	on-off /0-10V dim /Triac dim/Dali
BDLS5510	D64mm*H93mm	56*56mm	10W	275mA	31V/DC	8°/15°/24°/38°/50°	2700K-6000K	67Lm/w*10W	Ra＞90/97	on-off /0-10V dim /Triac dim/Dali
BDL7512	D75*H80mm	Ø75mm	12W	320mA	31V/DC	8°/15°/24°/38°/50°	2700K-6000K	67Lm/w*12W	Ra＞90/97	on-off /0-10V dim /Triac dim/Dali
BDL7512C	D84*H80mm	Ø75mm	12W	320mA	31V/DC	8°/15°/24°/38°/50°	2700K-6000K	67Lm/w*12W	Ra＞90/97	on-off /0-10V dim /Triac dim/Dali
BDL7512D	D84*H80mm	Ø75mm	12W	320mA	31V/DC	8°/15°/24°/38°/50°	2700K-6000K	67Lm/w*12W	Ra＞90/97	on-off /0-10V dim /Triac dim/Dali
BDLS7512	L85*H91	76*76mm	12W	320mA	31V/DC	15°/25°/35°/60°	2700K-6000K	67Lm/w*12W	Ra＞90/97	on-off /0-10V dim /Triac dim/Dali
BDLS7512-C	L85*H91	76*76mm	12W	320mA	31V/DC	15°/25°/35°/60°	2700K-6000K	67Lm/w*12W	Ra＞90/97	on-off /0-10V dim /Triac dim/Dali
BDLS7512-D	L85*H91	76*76mm	12W	320mA	31V/DC	15°/25°/35°/60°	2700K-6000K	67Lm/w*12W	Ra＞90/97	on-off /0-10V dim /Triac dim/Dali
BDLS7512-E	L85*H91	76*76mm	12W	320mA	31V/DC	15°/25°/35°/60°	2700K-6000K	67Lm/w*12W	Ra＞90/97	on-off /0-10V dim /Triac dim/Dali
BDL7520	D84*H110mm	Ø75mm	20W	550mA	31V/DC	8°/15°/24°/38°/50°	2700K-6000K	67Lm/w*20W	Ra＞90/97	on-off /0-10V dim /Triac dim/Dali
BDL7520-A	D84*H100mm	Ø75mm	20W	550mA	31V/DC	10°/15°/24°/38°/50°	2700K-6000K	67Lm/w*20W	Ra＞90/97	on-off /0-10V dim /Triac dim/Dali
BDL7520C	D84*H110mm	Ø75mm	20W	550mA	31V/DC	8°/15°/24°/38°/50°	2700K-6000K	67Lm/w*20W	Ra＞90/97	on-off /0-10V dim /Triac dim/Dali
BDL7520D	D84*H110mm	Ø75mm	20W	550mA	31V/DC	8°/15°/24°/38°/50°	2700K-6000K	67Lm/w*20W	Ra＞90/97	on-off /0-10V dim /Triac dim/Dali
BDLS7520	D85*H121mm	76*76mm	20W	550mA	31V/DC	15°/25°/36°/50°	2700K-6000K	67Lm/w*20W	Ra＞90/97	on-off /0-10V dim /Triac dim/Dali
BDLS7520-A	D85*H116mm	75*75mm	20W	550mA	31V/DC	10°/15°/24°/38°/50°	2700K-6000K	67Lm/w*20W	Ra＞90/97	on-off /0-10V dim /Triac dim/Dali
BDLS7520-C	D85*H121mm	76*76mm	20W	550mA	31V/DC	15°/25°/35°/60°	2700K-6000K	67Lm/w*20W	Ra＞90/97	on-off /0-10V dim /Triac dim/Dali
BDLS7520-D	D85*H121mm	76*76mm	20W	550mA	31V/DC	15°/25°/35°/60°	2700K-6000K	67Lm/w*20W	Ra＞90/97	on-off /0-10V dim /Triac dim/Dali
BDLS7520-E	D85*H121mm	76*76mm	20W	550mA	31V/DC	15°/25°/35°/60°	2700K-6000K	67Lm/w*20W	Ra＞90/97	on-off /0-10V dim /Triac dim/Dali
BDLS7520-D	D85*H121mm	76*76mm	20W	550mA	31V/DC	15°/25°/35°/60°	2700K-6000K	67Lm/w*20W	Ra＞90/97	on-off /0-10V dim /Triac dim/Dali
BDLS7520-E	D85*H121mm	76*76mm	20W	550mA	31V/DC	15°/25°/35°/60°	2700K-6000K	67Lm/w*20W	Ra＞90/97	on-off /0-10V dim /Triac dim/Dali
BDL9520	D111*H110mm	Ø95mm	20W	550mA	31V/DC	15°/24°/38°/60°	2700K-6000K	67Lm/w*20W	Ra＞90/97	on-off /0-10V dim /Triac dim/Dali
